| Name | 32″ Open Frame Touch Monitor |
| Model | OTL326 |
| LCD Panel Parameters | |
| Display Technology | Active Matrix TFT-LCD with LED Backlight |
| Aspect Ratio | 16:9 |
| Active Area (W x H) | 698.4 × 392.86 mm |
| Native Resolution | 1920 × 1080 @ 60 Hz |
| Response Time (Typ.) | 8 ms |
| Display Colors | 16.7 million |
| Luminance (Typ.) | 400 nits; with P-Cap 340 nits |
| Contrast Ratio (Typ.) | 1200:1 |
| Viewing Angle (Typ.) | Horizontal (left/right) CR≥10 89°/89° |
| Vertical (up/down) CR≥10 89°/89° | |
| Touch Screen Parameters | |
| Touch Technology | PCAP |
| Surface Treatment | Strengthened Optional: Anti-Glare |
| Active Area | 698.4 × 392.86 ± 0.3 mm |
| Thickness (Total) | 3.3 ± 0.3 mm |
| Light Transmission | ≥85% |
| Response Time | 10 ms |
| Touch Screen Interface | USB |
| Touch Point | 10 |
| Overall Parameters | |
| Case/Bezel Color | Gray back cover |
| Mounting Options | VESA: 200 × 200 mm; Side Mounting |
| Outline Dimensions（W×H×D） | 757.12mm × 450.6mm × 45.05mm |
| Power Supply | Input Voltage Range: 100-240V AC, 50-60 Hz |
| On Screen Display (OSD) | Control (back): Power, Auto, Up, Down, Menu |
| Power Consumption | MAX: 60W |
| Operating Altitude | ≦3000 m |
| Temperature Range | Operating: 0℃ to 40℃, Storage: -20℃ to 60℃ |
| Humidity (Non Condensing) | Operating: 20% to 80%, Storage: 10% to 90% |
| I/O | VGA, HDMI, USB (Type B) |
| Accessories | Cables: VGA × 1, USB × 1, 1.5 m Length |
| Carton Box Dimensions | 910 mm (L) × 220 mm (W) × 630 mm (H) |
| Weight | Gross: 20.65 Kg Net: 13.6 Kg |
| MTBF | 50,000 Hours Demonstrated |
| Agency Approvals | CE, FCC |
| Warranty | 3 Years |
| Ordering Information | ||
| Part Name | Part Number | Description |
| OTL326-RPCZ04-UHDAGN4 | 10202010121R | 32”, 16:9, 400nits, P-Cap, USB, VGA & HDMI, Gray |
