Name |
21.5 Inch Open Frame Touchmonitor |
|
Model |
RTL22W |
|
LCD Panel Parameters |
|
|
Display Technology |
Active Matrix TFT-LCD With LED Backlight |
|
Aspect Ratio |
16 : 9 |
|
Active Area (W × H) |
476.64 mm × 268.11 mm |
|
Native Resolution |
1920 × 1080 @ 60 Hz |
|
Response Time (Typ.) |
18 ms |
|
Display Colors |
16.7 million |
|
Luminance (Typ.) |
250 nits; with SAW 225 nits |
|
Contrast Ratio (Typ.) |
3000 : 1 |
|
Viewing Angle (Typ.) |
Horizontal (left/right) CR≥10 89°/89° |
| Vertical (up/down) CR≥10 89°/89° | |
|
Touch Screen Parameters |
|
|
Touch Technology |
SAW |
|
Surface Treatment |
Optional: Anti-glare |
|
Active Area |
476.50 mm × 268.00 mm |
|
Thickness (Total) |
4.00 ± 0.2 mm |
|
Light Transmission |
≥90% |
|
Response Time |
10.4 ms |
|
Touch Screen Interface |
USB / RS232 |
|
Touch Point |
1 |
|
Overall Parameters |
|
|
Case/Bezel Color |
Gray |
|
Mounting Options |
Side Mounting, VESA: 75 × 75 mm, 100 × 100 mm |
|
Outline Dimensions（W×H×D） |
537.27 mm × 328.27 mm × 43.40 mm |
|
Power Supply |
Input Voltage Range: +12V DC ± 5%, Coaxial power jack 2.5mm pin outer diameter |
|
On-Screen Display (OSD) |
Control (back): Power, Auto, Up, Down, Menu |
|
Power Consumption |
MAX: 35W |
|
Operating Altitude |
≦3000 m |
|
Temperature Range |
Operating: 0℃ to 40℃, storage: -20℃ to 60℃ |
|
Humidity (Non-Condensing) |
Operating: 20% to 80%, storage: 10% to 90% |
|
I/O |
VGA, DVI, USB (Type B）, RS232 |
|
Accessories |
Cables: VGA×1, USB×1, 1.5m Length |
|
Carton Box Dimensions (1 unit in one carton) |
715mm × 505mm × 205mm |
|
Weight |
Gross: 10 Kg Net: 8 Kg |
|
MTBF |
50,000 hours demonstrated |
|
Agency Approvals |
CCC, CE, FCC |
|
Warranty |
3 Years |
| Ordering Information | ||
| Part Name | Part Number | Description |
| RTL22W-RZ04-SUCDA | 10201010114R | 21.5″, 16:9, 250nits, Zero Bezel SAW, USB & RS232, VGA/DVI |
